Jack nối dây mạng cổng RJ45 Neutrik NE8FF/ 1 Cái
Thông Tin Kỹ Thuật
propk
Title
NE8FF
Connection Type
Adapter
Gender
female
Electrical
Contact resistance
< 10 mΩ
Dielectric strength
1 kVdc
Frequencyrange
1 - 100 MHz
Insulation resistance
> 0.5 GΩ
Rated current per contact
1,5 A
Rated voltage
< 50 V
Standard compliance
TIA/EIA 586B, IEC11801
Mechanical
Insertion force
≤ 20 N
Withdrawal force
≤ 20 N
Lifetime
> 1000 mating cycles
Locking device
Latch lock
Material
Contact plating
0.2 µm Au over Ni plating
Contacts
Bronze (CuSn8)
Insert
PBTP 15 % GR
Shell
AlMgSi 0.5, black plated
Strain relief
CuZn35Pb2, Tin plated
Environmental
Flammability
UL 94 HB
Temperature range
-30 °C to +80 °C
