Onkyo CS-555

Thông Tin Kỹ Thuật

Rated Output Power

 All channels: (European)

2 ch × 22 W at 4 ohms, 1 kHz, 2 ch driven

of 0.4% (IEC)

Damping Factor 22 (Front, 1 kHz, 8 Ω)

THD+N (Total Harmonic Distortion+Noise)

0.4% (1 kHz, 1 W)

Input Sensitivity and Impedance (Unbalance)

150 mV/47 kΩ (LINE)

Rated RCA Output Level and Impedance

0.15 V/330 Ω (LINE OUT)

Frequency Response 10 Hz - 100 kHz/±3 dB (LINE1)

Tone Control Characteristics

±6 dB, 80 Hz (BASS)

±8 dB, 10 kHz (TREBLE)

+8 dB, 30 Hz (PM.Bass)

Signal to Noise Ratio 100 dB (LINE, IHF-A)

Speaker Impedance 4 Ω - 16 Ω

FM Tuning Frequency Range 87.5 MHz - 108.0 MHz, RDS

(Others) 87.5 MHz - 108.0 MHz

AM Tuning Frequency Range (CR-555) 522 kHz - 1611 kHz

Preset Channel 40

Signal Readout Optical non-contact

Frequency Response 10 Hz - 20 kHz

Audio Dynamic Range 96 dB

THD (Total Harmonic Distortion) 0.025%

Wow and Flutter Below threshold of measurability

Audio Output/Impedance (Analog) 2.0 V (rms)/330 Ω

Power Supply AC 220 - 230 V, 50/60 Hz

Power Consumption (CR-555) 72 W

(CR-555DAB) 77 W

No-sound Power Consumption

(CR-555) 30 (USB 1ALoad) W

(CR-555DAB) 35 W

(USB 1ALoad:DAB)

Stand-by Power Consumption

(CR-555) 0.26 W

(CR-555DAB) 0.27 W

Dimensions (W × H × D) 215 mm × 119 mm × 331 mm

Weight 4.8 kg

Digital Optical: 1 Coaxial: 1

Analog LINE1, LINE2, AUX

Analog LINE OUT

Subwoofer Pre Output 1

Speaker Outputs Main (L, R)

Phones 1 (3.5 ø
